HRF-MX2 Series foot switch features a robust frame crafted from
stretch-formed carbon steel plates, ensuring high strength and a long
service life. The unit delivers superior protective performance and a
sleek appearance. A durable plastic coating provides excellent resistance
to impact, abrasion, and high temperatures (up to 180°C).
  | |
 Built-in Switch | 5: M5 switch box V: V15F-01C micro switch F: Waterproof micro switch |
 LED Indicator | No mark: No L: LED |
 Aviation Plug | No mark: No P : Aviation plug |
 Pedal Number | No mark: 1 Pedal 2P: 2 Pedals 3P: 3 Pedal 4P: 4 Pedals 5P: 5 Pedals 6P: 6 Pedals |
| Part Number | Picture | Contact Form | Rated Load | Built-in Switch | Certification | Material | Cable outlet | Degree of Protection |
| HRF-MX2 |  | 1C | 8A 250VAC | V15F-01C (UL,CUL,VDE, CE,KC,CQC certified) |  | Rolled steel sheets | RVV 20AWG ×3Line Cable×2m | IP54 |
*Forothercustomizedmodels,pleasecontactwith usdirectly
| HRF-MX2 |
 |
