HRF-M3 series plastic foot switch with small size and elegant in appearance,
it offers high cost performance and is suitable for control in various machinery and equipment.
Made of flame-retardant engineering plastic ABS, it features high structural strength,
impact resistance and wear resistance.
  | |
 Pedal Number | No mark : 1 Pedal 2: 2 Pedals |
 Pedal Color | Y: Yellow B: Blue YB: Left-yellow , right-blue K: Black C: Grey |
 Built-in Switch | No mark: Waterproof micro switch |
 Contact Mode | No mark: Single W: Double switches |
 Connector | No mark: Standard (Without ) A: 6.3mm Audio connector D: DB9 serial port U: USB connection |
| Part Number | Picture | Contact Form | Rated Load | Built-in Switch | Certification | Material | Cable outlet | Degree of Protection |
| HRF-M3 |  | 1A | 5A 250VAC | V15F-01C (UL, CUL, VDE, CE, KC, CQC certified) + 24k gold plat |  | Plastic | RVV 20AWG ×2Line Cable×2m | IPX7 |
*Forothercustomizedmodels,pleasecontactwith usdirectly
| HRF-M3 |
 |
